Specifications:
1) Dimensions (L x W x H) (mm): 1,900 x 795 x 1,010
2) Ground clearance (mm): 140
3) Net weight (kg): 105
4) Max loading (kg): 150
5) Engine type: 157FMI (single air-cooled 4 stroke)
6) Displacement (ml): 124
7) Start method: electric/kick
8) Ignition: CDI
9) Economical Fuel Consumption: 2.1L/100km
10) Fuel tank max capacity: 12L
11)Rated power:7.2kw/rpm(9000+500r/min)
12)Max torque: 8.0N.m/rpm(7000-500r/min)
13) Brake (front/rear): drum/drum
14)Tires: Fr: 2.5-18 / Rr: 2.75-18
15)Max speed (km/h): 85
Load quantity:
SKD: 54PCS/20GP, 120PCS/40GP, 126PCS/40HQ
CKD: 90SETS/20GP, 180SETS/40GP, 210SETS/40HQ
* 20GP: 20ft container, 40GP: 40ft container, 40HQ: 40ft high container
* SKD: Semi-knocked down, CKD: Complete-knocked down
Optional condition:
+ Engine available: 125cc/150cc/200cc
+ Wheel: Alu alloy wheel / spoke wheel
+ Front brake: Disc / drum
+ Head cover
+ Remote control
+ Leg guard
+ Rear carrier: Small carrier / Big carrier with big foot rest
+ Color available: Red/Blue (or as your requirements)
More photos:
